High Speed Automatic Splicers

Get Latest Price

Min. Order:

1 Others

Contact Now

Product Description

Packaging & Delivery

Product Description

Packaging & Delivery

Selling Units

Others

The file is encrypted. Please fill in the following information to continue accessing it

Product Description

Technical parameters：

Working wide：2200mm

Link paper speed：200m/min

Air pressure：6 bpa

Structural feature：

The maximum diameter of the applicable paper：1500mm.
With the automatic tension control of the original paper holder, the paper can be picked up at high speed and the success rate is high.
No tail paper receiving, reducing paper consumption (only partially overlapping paper tape with a width of 40mm).
When paper car take out, the automatic turn out, and the vacuum adsorption, easy paper loading, automatic tension control paper receiving zero turnovers.
All PLC automatic control, accurate, less failure, easy maintenance.
The first round of the buffer when you pull the paper, automatic alignment, easy to pull paper.
Machine superiority cylinder control speed splicers paper receiving moment does not appear normal motor control of rubble, blistering.
Paper receiving highest speed of 200 m / min.

Main component parameters：

Part name Craftsmanship	Specification	Material	Surface treatment
Upper paper guide shaft	￠137mm	45＃ steel	Round grinding chrome
Lower paper guide shaft	￠150mm	45＃ steel	Round grinding chrome
Buffer reel guide roller 1	￠126mm	45＃ steel	Round grinding chrome
Buffer reel guide roller 2	￠137mm	45＃ steel	Round grinding chrome
Pinch paper roller	￠99mm	45＃ steel	Round grinding chrome
Hold paper roller	￠99mm	45＃ steel	Round grinding chrome

Mainly purchased parts, raw materials and origin:

Serial number	Name of main parts	Brands or place of origin	Remarks
01	Breaker	Schneider
02	Contactor	Schneider
03	Relay	Schneider
04	Left and right conversion solenoid valve	Japan SMC
05	Precision pressure regulator	Japan SMC
06	Electric proportional valve	Japan SMC
07	Speed increase relay	Japan SMC
08	Filter	Japan SMC
09	Wire rope	American Smurfs	Aviation equipment
10	Sealing ring	American Parker
11	Proximity switch	Omron Japan
12	PLC	Taiwan Delta
13	Geared motor	Taiwan Takasaki
14	The electromagnetic valve	TaiWan AirTAC
15	Cylinder	STNC

We are a manufacturing enterprise specializing in the production of Corrugated Cardboard Production Line and Corrugated Board Production Line. In addition to the complete production line, standalone Cardboard Machinery is also being sold. Having a professional technical team and complete production equipment, we can provide customers with high-quality and efficient products and services.
